    6*4 Drive Mode Special Purpose Vehicles SHACMAN Used Concrete Mixer Trucks

    Ask Lasest Price
    Brand Name : SHACMAN
    Model Number : Concrete Mixer truck
    Certification : ISO, CCC, CE
    Price : negotiable
    Payment Terms : T/T
    Supply Ability : 100 units per month
    Delivery Time : normally 7 working days after full payment received
    • Product Details
    • Company Profile

    6*4 Drive Mode Special Purpose Vehicles SHACMAN Used Concrete Mixer Trucks

    99 Km/H Max Speed 6*4 Drive Mode SHACMAN Second Hand Concrete Mixer Trucks

    Concrete Mix Truck parameters
    Product nameConcrete Mixer truckVehicle BrandSHACMAN
    Overall dimensions10450X2495X3950mmCurb weight16000kg
    Loading capacity12m3Year2012-2017
    Chassis parameters
    Chassis modelSX1250FBChassis brandSHACMAN
    Overall dimensions8600x2495x3270mmWheel base3975+1400mm
    Front/rear wheel track2011/1860/1860mmFront/rear suspension1525/1700mm
    Approach/departure angle18/11°Maximum speed99km/h
    Chassis ManufacturerShanxi Automobile Group Co., Ltd.
    CabConfigurationF3000 half cab(with sleeping berth),allowable 3 passengers
    ColorWhite,other color is optional
    EngineModelWP10.336E53
    EmissionEuro 5
    Type6 cylinders,in-line,4-stroke,water-cooled,turbo inter-cooling,direct injection, exhaust valve brake,diesel engine
    Rated power336hp,rated power speed 1900rpm
    Displacement9726ml
    Bore x stroke126x130mm
    ManufacturerWeichai Power Co.,Ltd
    TireSize12.00R20 steel wire tire
    Number10+1 nos
    Clutchφ430 diaphragm clutch
    Fuel tank400L Aluminum fuel tank
    Front axle7.5 tons
    Rear axle16.0 tons STR rear axle
    Drive form6X4
    Rated voltage24V,DC
    TransmissionsGearbox RTD11509C, 9 speed forward 1 reverse
    Steering devicePower assisted steering
    Steering wheelLeft hand drive
    Selective configuration
    If there is a slight change in the chassis parameters above,please take the actual product as the standard

    Concrete mixer truck structure parameters
    Mixing capacity(m³)12Color and LogoOptional
    Feeding speed (m³/min)≥8Discharge speed(m³/min)≥5
    Discharge residual rate≤0.5%Slump scope(mm)50-210
    Water tank capacity(L)300Water pressure(Mpa)0.35-0.38
    Tank material5mm alloy steelTank front head8mm alloy steel
    ReducerBONFIGLIOLIHydraulic motorGermany REXROTH
    Hydraulic pumpGermany REXROTHRadiatorKAIPENG
    Standard configurationchassis,sub frame,mixer tank,reducer, hydraulic pump,hydraulic motor, radiator,water tank,cleaning hose,feed port, discharge port,climbing ladder,air pressure water supply device.
    12m3Italy Bonfiglioli reducer,Germany REXROTH hydraulic pump,Germany REXROTH hydraulic motor,KAIPENG radiator,mixer tank(main tank 6mm alloy steel wear resistant material,front tank head 8mm alloy steel wear resistant material)
    Selective configuration

    Emergency high pressure oil hose(4 pieces),12m emergency oil hose(Italy),water cannon,large tool box,electric water supplying system.

    Germany ZF/Italy PMP reducer, Italy PMP/Italy MESSORI/America EATON/America SAUER hydraulic pump, hydraulic motor.

    We have a wide range of quality used trucks in our stock. One of the benefits of purchasing an used concrete mixer truck from us is the vehicle support provided to you in the event of any issue.

    All used concrete mixer trucks for sale undergo rigid testing for any problems and comprehensive repairs are undertaken before the truck is listed for sale and we use only genuine original factory spare parts.

    Regular Trade Terms:

    Packing : Nude packing.

    Shipment: By RO-RO or Bulk vessel .

    Payment terms: T/T before shipment.

    Delivery time: normally 7 working days after full payment received.

    Used Vehicles we can provide

    Used Buses like yutong bus,coaster bus, coach bus,tour bus,mini bus,school bus etc.

    Used trucks like dump trucks, sinotruck, cargo truck, tractor trucks, crane truck, concrete mixer trucks and other special purpose trucks, etc.

    Used SUVs and used pickup cars, we can also source used vehicles based on your demands.
